Page 185

185
Type
Member types displayed include Static or Dynamic, depending on selected
options.
Life(Sec)
Display the current life.
4.7.4.4 MLD Router Setting
Depending on your network connections, MLD snooping may not always be able to locate the MLD querier. Therefore,
if the MLD querier is a known multicast router/ switch connected over the network to an interface (port or trunk) on your
Managed Switch, you can manually configure the interface (and a specified VLAN) to join all the current multicast
groups supported by the attached router. This can ensure that multicast traffic is passed to all the appropriate
interfaces within the Managed Switch.
The MLD Router Setting screens in
Figure 4-7-27
&
Figure 4-7-28
appear.
Figure 4-7-27
Add Router Port Page Screenshot
The page includes the following fields:
Object
Description
VLAN ID
Selects the VLAN to propagate all multicast traffic coming from the attached
multicast router.
Type
Sets the Router port type. The types of Router port as below:
Static
Forbid
Static Ports Select
Specify which ports act as router ports. A router port is a port on the Ethernet
switch that leads towards the Layer 3 multicast device or MLD querier.
Forbid Port Select
Specify which ports un-act as router ports.
Buttons
