132
Figure 4-5-19
GVRP Port Error Statistics Page Screenshot
The page includes the following fields:
Object
Description
Port
The switch port number of the logical port.
Invaild Protocol ID
Display the current invalid protocol ID.
Invalid Attribute Type
Display the current invalid attribute type.
Invalid Attribute Value
Display the current invalid attribute value.
Invalid Attribute
Length
Display the current invalid attribute length.
Invalid Event
Display the current invalid event.
Buttons
: Click to clear the GVRP Error Statistics.
: Click to refresh the GVRP Error Statistics.
4.5.14 VLAN setting example:
- Separate VLANs
- 802.1Q VLAN Trunk
4.5.14.1 Two separate 802.1Q VLANs
The diagram shows how the Managed Switch handle Tagged and Untagged traffic flow for two VLANs. VLAN Group 2
and VLAN Group 3 are separated VLANs. Each VLAN isolate network traffic so only members of the VLAN receive
traffic from the same VLAN members. The screen in
Figure 4-5-20
appears and
Table 4-5-2
describes the port
configuration of the Managed Switches.
