4.2.7.3 SNMP View
Configure SNMPv3 view table on this page. The entry index keys are View Name and OID Subtree. The SNMPv3
View Table Setting screens in
Figure 4-2-23
and
Figure 4-2-24
appear.
Figure 4-2-23
SNMPv3 View Table Setting Page Screenshot
The page includes the following fields:
Object
Description
View Name
A string identifying the view name that this entry should belong to.
The allowed string length is 1 to 16.
Subtree OID
The OID defining the root of the subtree to add to the named view.
The allowed string content is digital number or asterisk (*).
Subtree OID Mask
The bitmask identifies which positions in the specified object identifier are to be
regarded as "wildcards" for the purpose of pattern-matching.
View Type
Indicates the view type that this entry should belong to. Possible view type are:
included
: An optional flag to indicate that this view subtree should be included.
excluded
: An optional flag to indicate that this view subtree should be
excluded.
General, if a view entry's view type is 'excluded', it should be exist another view
entry which view type is 'included' and it's OID subtree overstep the 'excluded'
view entry.
Buttons
: Click to add a new view entry.
