“DSTRBT” means distributing state
Receive
LACP receive state machine status of the port.
“INIT” means the port is in initialize state
“PORTds” means port disabled state
“EXPR” means expired state
“LACPds” means LACP disabled state
“DFLT” means defaulted state
“CRRNT” means current state.
PrdTx
LACP periodic transmission state machine status of the port.
“no PRD” means the port is in no periodic state
“FstPRD” means fast periodic state
“SlwPRD” means slow periodic state
“PrdTX” means periodic TX state
AtState
The actor state field of LACP PDU description.
The field from left to right describes: “LACP_Activity”, “LACP_Timeout”,
“Aggregation”, “Synchronization”, “Collecting”, “Distributing”, “Defaulted”, and
“Expired”.
The contents could be true or false. If the contents are false, the web shows
“_”; if the contents are true, the web shows “A”, “T”, “G”, “S”, “C”, “D”, “F” and
“E” for each content respectively.
PnState
The partner state field of LACP PDU description.
The field from left to right describes: “LACP_Activity”, “LACP_Timeout”,
“Aggregation”, “Synchronization”, “Collecting”, “Distributing”, “Defaulted”, and
“Expired”.
The contents could be true or false. If the contents are false, the web shows
“_”; if the contents are true, the web shows “A”, “T”, “G”, “S”, “C”, “D”, “F” and
“E” for each content respectively.
