 HDD Group is only available for read-write HDD and self-defined disks, other types of hard
disks cannot be set as HDD Group.
HDD Setting
Click the button “HDD Settings” at the top right corner of the Figure 5-48, system will pop up an interface
as below. See Figure 5-50.
 HDD: Here you can view the HDD amount the device can support. If there is a mark
in the
front of the number, it means current position has installed a HDD.
 HDD Group: It lists the HDD Group number of current hard disk.
When you are setting the HDD Group, please check the box of the hard disk, and then choose the
corresponding HDD Group number and save the settings.
Please note, one HDD is corresponding to one group, while one group can have many HDDs. The HDD
group No. is corresponding HDD port, the HDD group No. may vary if you change the HDD.
In Figure 5-50, you can see the system has two working hard disks at the first and second position, and
the first hard disk belongs to HDD Group 1, the second hard disk belongs to HDD Group 2.
Important
Once you change the HDD Group settings, system will reboot!
Figure 5-50
Channels Setting
Click the button named with “Channels Settings” at the top right corner of the Figure 5-48, system will
pop up an interface shown as in Figure 5-51.
Channel: Here you can view the actual channel amount of the device.
Group No.:It is the SN in the HDD group management. Here we can set HDD 1 and HDD 2 sets to as
HDD group 1 and HDD group 2 respectively. You can see the HDD group option has only two options 1
and 2 when you set corresponding HDD group of the channel.
When you set the channel setup, please select the corresponding channel such as 1 and 2, and then
select the HDD group such as 1. Click the Save button, you can complete the setup.
In the Figure 5-51, you set channel 1 and channel 3 to the corresponding HDD group1 and set channel 2
and channel 4 to HDD group 2. In this setup, the records from channel 1 and channel 3 are both saved
in HDD of the group 2. The records from channel 2 and channel 4 are all saved in HDD of the group 2.
