137
Figure 7-78
Please refer to the following sheet for detailed information.
Parameter Function
Resolution
There are four options: 1920Ч1080,1280Ч1024(default),1280Ч
720,1024Ч768. Please note the system needs to reboot to
activate current setup.
Transparency Here is for you to adjust transparency. The value ranges from 128
to 255.
Time
title/channel
title
Check the box here, you can view system time and channel
number on the monitor video.
enhance
Check the box; you can optimize the margin of the preview video.
7.8.5.3.2 Tour
The tour interface is shown as in Figure 7-79. Here you can set tour interval, split mode, motion detect
tour and alarm tour mode.
Figure 7-79
Please refer to the following sheet for detailed information.
