91
Figure 6-4
Here is a sheet for you reference.
Name Function
key function Shortcut
key Function
key function Shortcut
key
Zoom Near Far

Focus Near │  Far ► │
Iris close  
Open

6.2 Preset /Patrol / Pattern /Border Function
In
X402H402H 402H
Figure 6-2
X
click the set button. The interface is shown as below:
Here you can set the following items:
 Preset
 Patrol
 Pattern
 Border
Figure 6-5
In
X403H403H 403H
Figure 6-2
X
, click page switch button, you can see an interface as in
X404H404H404H
Figure 6-6
X
.
Here you can activate the following functions:
 Preset
 Tour(Patrol)
 Pattern
 Auto scan
 Auto pan
 Flip
 Page Switch
Figure 6-6
6.2.1 Preset Setup
