123
Figure 7-50
Please refer to the following sheet for detailed information.
Parameter Function
Enable You need to check the box to enable motion detection function.
Please select a channel from the dropdown list.
Period Motion detection function becomes activated in the specified
periods. See Figure 7-48.
There are six periods in one day. Please draw a circle to enable
corresponding period.
Click OK button, system goes back to motion detection interface,
please click save button to exit.
Sensitivity
There are six levels. The sixth level has the highest sensitivity.
Region There are six levels. The sixth level has the highest sensitivity.
Region: If you select motion detection type, you can click this
button to set motion detection zone. The interface is shown as in
Figure 7-49. There are PAL 22X18/NTSC 22X15 zones. Right
click mouse you can go to full-screen display mode. Do remember
clicking OK button to save your motion detection zone setup.
Record
channel System auto activates motion detection channel(s) to record once
an alarm occurs. Please note you need to set motion detect
record period and go to Storage-> Schedule to set current
channel as schedule record.
Record Delay System can delay the record for specified time after alarm ended.
The value ranges from 10s to 300s.
Show
message System can pop up a message to alarm you in the local host
screen if you enabled this function.
Buzzer Check the box here to enable this function. The buzzer beeps
when an alarm occurs.
Alarm upload System can upload the alarm signal to the centre (Including alarm
centre.
Message When 3G network connection is OK, system can send out a
message when motion detect occurs.
Send Email If you enabled this function, System can send out an email to alert
you when an alarm occurs.
Tour You need to check the box here to enable this function. System
begins 1-wiindow or multiple-window tour display among the
channel(s) you set to record when an alarm occurs.
Please go to chapter 5.3.7 to set tour interval and tour mode.
