Connection to an External Device
Connect the external device properly to the unit by using input jacks either L2 (Front) or LI (Rear).
.................
When connecting an external device of monaural output to this unit, use AUDIO L jack of L2 (Front).
Use S-video or the RCA audio/video cables for this connection.
When connecting a DVC (digital video camcorder), use the DV input jack on the front panel instead of VIDEO IN jack.
external device
(camcorder, VCR etc.)
L.... ...............................—
¿r“ll.......
........... .............................
front of this unit I
rear of this unit
used in this connection i
le(L/R)x1
’
