9. Input the signals sent to the adat into channels 1 and 2
9.
Input the signals sent to the adat into channels 1 and 2
Input the return of the signals sent to the adat into channels 1 and 2, and send the stereo output
directly to the monitor. This is so you can "monitor" the signals from tape.
O
In I/S/P mode, set the Input of channel 1 to "DIG-Al," and the Input of channel 2 to "DIG-
A2."
+.. PGM Ch 1 >Ifi.''Serid.''p.=in SOL Cl
Auxl Aux2 E f f l E f f 2
o o o o
U ■ U I U ■
k
.1
o o o
o
Post Post Post Post
Pan
O
O In I/S/P mode, set the channel 1 and 2 Aux (Aux Send) 1 and 2 Levels to "0".
O In I/S/P mode, set the channel 1 and 2 Eff (Effect Send) 1 and 2 Levels to "0".
O
In I/S/P mode, set the channel 1 Pan to "L50", and the channel 2 Pan to "R50"
0 In EQ mode, turn the EQ In "OFF" for channels 1 and 2.
In the Bus Assign page of BUS mode, turn Master "ON" and all others "OFF" for channels 1
and 2.
Master
DEI
ST-Group Ql
BH3
r
GIO G20 G3Q) G40 G5Q) G60 G70 GSO
OFF OFF OFF OFF OFF OFF OFF OFF
O Switch the [MUTE] key off (LED dark) for channels 1 and 2.
O Raise the channel faders 1 and 2 to the 0 dB position.
21
