KEYENCE GP-M Series - Manual (Page 25)

25
Dimensions
(27.5)
44.3
86.7
ш34.2 44.6
ш30
(T
wo surface width)
27
29.2
2.6
15.4
G3/4 A
Useable length 10
M12 × 1
Detecting element
ø11 depth 1.2 (GP-M001/M010/M025)
ø7 depth 2.9 (GP-M100/M250/M400)
*
* There is no air hole
on the GP-M100/
M250/M400.
(Unit : mm)
ш19.5
ш22.5
1.5 A-A
A A
ш15
ш8
ш12.8
2.4 A-A 1.9
A A
O-ring
for GP-M001/M010/M025 use
O-ring set
for GP-M100/M250/M400 use
