Change the setting value of output 1. The changing of setting values
of output 2 is done by pressing and holding the MODE button.
(Refer to page 15)
Changing the Setting Value of Output 1
Display Pressure Unit/Hold Display
Push briefly
MODE
*4
*2
*3
52
Push briefly
MODE
Switch-on point 1
Select using the
buttons.
Setting range: 1% of F.S. to 100% of F.S.
(Details on page 17)
Switch-off point 1
Select using the
buttons.
Setting range: 0% of F.S. to
(Switch-on point) -1% of F.S.
(Details on page 17)
Finish settings
Return to main
screen
Alternate
T2
Alternate
Press or briefly
*1
*3. The detection mode of the Output 1 is
displayed
as “
(.” when in window mode.
*4. If it is not used for 4 seconds it will return
to the main screen.
*1. The detection mode of the Output 1 is
displayed
as “
(*” when in window mode.
*2. If it is not used for 4 seconds it will return
to the main screen.
Display Pressure Unit
If the MODE button is pressed briefly on the main screen, the
pressure unit will display.
If it is not used for 2 seconds it will return to the main screen.
Display Peak and Bottom Hold
If the MODE button + the U (V) button are pressed briefly on
the main screen, the peak (bottom) hold value will display.
(“2A*” (“DA*”) and hold value will blink alternately.)
