- EtherNet/IP Compatible Network Unit DL-EP1 User’s Manual (FD-MH) -
2-2 Installation and Connection to Sensor Amplifiers
2-6
2
C
onn
ec
tion
and
C
onf
ig
ur
at
ion
Several sensor amplifiers can be connected to the DL-EP1. ID numbers for data
identification are assigned to each sensor amplifier.
The method for assigning ID numbers is as follows:
• ID numbers are assigned in order, starting from the sensor amplifier that is the
main unit. (Optional numbers cannot be assigned.)
• 0 is assigned as the ID number of the DL-EP1.
• You cannot change the ID numbers assigned to the sensor amplifiers.
• In this manual, ID number 00 to ID number 10 are denoted as ID00 to
ID10, respectively.
Also for cyclic communication, output, current value, and external input are assigned
one by one per ID number.
Assigning ID Numbers
Point
ID number 01
Main
unit
Expansion
unit
Expansion
unit
Expansion
unit
02 09 10 00
