RS-232C
Query control commands
Data transmitted by PC Description of command
[STX] QPB;m [ETX]
Parameter
m = D: Date information
T; Time information
C: Camera connection information
R: Recording time mode information
A: Alarm number information
O: Monitor screen display information
Queries the playback tape information.
Data returned from unit in response
[STX] LPBm:r:data [ETX]
Parameter
m = D: Date information
r = O: READ OK
N: READ NG
data = yyyymmdd
yyyy = 2000—2099: Gregorian
calendar
mm= 01—12; Month
dd= 01—31: Day
m = T: Time information
r = 0: READ OK
N: READ NG
data = hhmmss
hh= 00—23: Hours
mm — 00“~59: Minutes
ss = 00—59;
Seconds
m = C: Camera connection information
r = O: READ OK
N: READ NG
data = C13-16C9-12C5-SC1-4
C13-16 = 1—F:
Connection information for
camera No. 13—16
C9-i2= 1—F:
Connection information for
camera No.9—12
C5-S = 1—F:
Connection information for
camera No.5—8
Cl -4= 1—F:
Connection information for
camera No. 1—4
For details on C+, refer to the camera
connection information table.
m = R: Recording time mode information
r = 0; READ OK
N: READ NG
data = t
t = 0: 3*hour recording
1: 9-hour recording
2: 12-hour recording
3: 18-hour recording
4: 24-hour recording
5: 48-hour recording
6: 72-hour recording
7: 96-hour recording
8: 120-hour recording
9: 180-hour recording
A: 240-hour recording
B: 360-hour recording
C: 480-hour recording
D; 960-hour recording
m = A: Alarm number information
r = 0: READ OK
N: READ NG
data - nn
nn - 00—99: Alarm number
FF: No alarm data
m = O: Monitor screen display information
r = 0 ; READ OK
N; READ NG
data = xx:yy:did 2
XX
= 00—22:
Position of head character (in
horizontal direction)
Position from left when monitor screen
has been divided horizontally into 22
segments.
yy = 00—14:
Position of head character (in vertical
direction)
Position from top when monitor screen
has been divided vertically into 14
segments.
did2== 00—FF:
Monitor screen display ON/OFF
For details on d1d2, refer to the monitor
screen display information table.
95
