RS-232C
• Bitmap table (A)
ADDRESS BIT7 BIT6 BITS BIT4 BITS BIT2 BIT1 BITO
ADO 0 0 0 0 0 0 0 0
AD 1 0 0 0 0 0 0 0 0
AD 2
REC INHIBIT
TAB
CASSETTE
IN/OUT
0 VTR STATUS
AD3 0 0 0 0 0 0 0 0
AD 4 0 0 0 0 0 0 0 0
VTR STATUS DATA
BIT4—BITO VTR STATUS BIT4—BITO VTR STATUS
0.1, 1,1,1
FORWARD SEARCH
(7 X normal speed)
0, 0,1,1,1 PLAY PAUSE
0,1,1,1,0
REVERSE SEARCH
{7 X normal speed)
0, 0,1,1,0 PLAY
0,1,1,0,1
FORWARD SEARCH
(4x normal speed)
0, 0,1, 0,1
FORWARD SEARCH
(1X normal speed)
0,1,1,0,0
REVERSE SEARCH
(4x normal speed)
0, 0,1,0,0 POWER OFF
0,1,0,1,1
REVERSE SEARCH
{1 X normal speed)
0, 0, 0, 1,1 FAST FORWARD
0,1,0,1,0 REC REVIEW 0, 0, 0,1,0 REWIND
0.1,0, 0,1 REC PAUSE 0, 0, 0, 0,1 EJECT
0,1,0, 0,0 RECORDING 0, 0, 0, 0, 0 STOP
