RS-232C
I Time lapse control commands
These commands are not acknowledged while a search control command is being processed.
Data transmitted by PC Data returned from unit in response Description of command
[SIX] LDO:data1 :data2 [ETX]
Parameter
datal = hhmm (start time)
data2 = hhmm (end time)
hh = 00—23: Hours (24-hour
system)
mm = 00—59: Minutes
[STX] LDO [ETX] Sets the start time (START) and end time (END) at which
the control signals are to be output to the component
connected to EXT TIMER OUT on the rear panel terminal
section.
The control signals are not output when the same time has
been set for both the START and END times.
[SIX] LDP:m [ETX]
Parameter
m= H: HIGH
Recording at a high picture
quaiity
N: NORMAL
Recording at the standard
picture quality
F: NO CHANGE
Recording at the currently
set picture quality
(STX) LDP [ETX] For setting the picture quality with which to perform alarm
recording and/or sensor recording.
[SIX] LDS:m [ETX]
Parameter
m = 1: Field playback
R: Frame playback
[STX] LDS [ETX] For selecting field playback or frame playback for still-
picture playback.
[SIX] LDT:m;n [ETX]
Parameter
m = 0—7: Recording type of
ALARM IN 1
n - 0—7: Recording type of
ALARM IN 2
[STX] LDT [ETX] For setting the recording type to be used if an alarm signal
has been input to ALARM IN 1 or 2.
[STX] LDW:m [ETX]
Parameter
m = W: WARNING
Control signals continue to
be output.
R: REC
Control signals are output
only during recording.
[STX] LDW [ETX] Sets how the control signals are to be output to the
component connected to WARNING/REC OUT on the rear
panel terminal section when a problem has occurred in the
unit.
[STX] LDX:m [ETX]
Parameter
m= V; VIDEO OUT
Video signal output
connector
E: EXTSWIN
External sequential
switcher signal input
connector
[STX] LDX [ETX] Switches the function of the rear panel EXT SW IN/VIDEO
OUT connector.
77
