RS-232C

(4) List of commands

The tables below show the send commands for each mode as seen from the PC side and the operations of
those commands.
“STX” is hexadecimal code 02H, “ETX” is hexadecimal code OSH, : is hexadecimal code 3AH, and the

“discrimination” and “data” parts signify the ASCII codes corresponding to their symbols.

• Communication control commands

Data transmitted by PC

Data returned from unit in response

Description of command

[STX] RAF [ETX]

Sets the ACK (acknowiedge) code return function to OFF.

[STX] RAN [ETX]

Sets the ACK (acknowledge) code return function to ON.

[STX] RCK [ETX]

Checks the communication line.

[STX] RSE:m [ETX]

[STX] RSE [ETX]

Sets the search end mode.

• Counter control commands

Data transmitted by PC

Data returned from unit in response

Description of command

[STX] CCP:data [ETX]

[STX] CCP [ETX]

Presets the CTL counter data (same as the CLP

command).

[STX] CLP:data [ETX]

[STX] CLP [ETX]

Presets the CTL counter data (same as the CCP

command).

[STX] CRT [ETX]

Resets the CTL counter data.

• Display control commands

Data transmitted by PC

Data returned from unit in response

Description of command

[STX] DBB [ETX]

Sets the characters to black.

[STX] DBW [ETX]

Sets the characters to white.

[STX] DDS:d:t:m:r [ETX]

[STX] DDS [ETX]

Sets the display item on the monitor screen.

[STX] DFC:m [ETX]

[STX] DFC [ETX]

Set the display mode of the display tube.

[STX] DMS:d:m:n [ETX]

[STX] DMS [ETX]

Sets the time system (12-hour or 24-hour) display mode.

[STX] DPP:mm [ETX]

[STX] DPP [ETX]

Sets the display position on the monitor screen.
