RS-232C
I Time lapse control commands
These commands are not acknowledged while a search control command is being processed.
Data transmitted by PC Data returned from unit in response Description of command
[STX] LLL:m [ETX]
Parameter
m = N: Line-lock type
F: Internal sync and external
sync type
[STX] LLL [ETX] Sets the synchronization system of the camerays
connected.
• Use of the internal sync type of cameras Is
recommended.
• Select the ON setting when even one line-lock type of
camera is used.
[STX] LMA:m [ETX]
Parameter
m = F: Search mode OFF
M: Memory stop mode
A: Alarm search mode
[STX] LMA [ETX] Switches the search mode.
[STX] LMP;p:n [ETX]
Parameter
p = S: 1-screen display
0: 4-tn-1 screen display;
Selected screen No.O
1: 4-in-1 screen display;
Selected screen No.l
2: 4-in-1 screen display;
Selected screen No.2
3: 4-in-1 screen display;
Selected screen No.3
[STX] LMP [ETX] Switches the screen display (4-in-l or 1-screen display) and
sets the camera numbers.
0 1
2 3
n= Camera No. is not
changed.
0—F: Carhera No.l to 16;
Camera number is
designated for the
screen No. selected by
parameter p.
[STX] LNR:f;p;t [ETX]
Parameter
f = 1; Field recording
R: Frame recording
[STX] LNR [ETX] Sets the recording mode, picture quality and recording type.
p= H: HIGH
Recording at a high picture
quality
N: NORMAL
Recording at the standard
picture quality
t = 0—7: Recording type
(RTO—7)
79
