INSTALLATION PROCEDURES

3-8

regulation provided in an L.P. dryer. The water column pressure must be regulated at the source
(L.P. tank) or an external regulator must be added to each dryer.

3.

Piping / Connections

All components / materials must conform to National Fuel Gas Code Specifications or in

CANADA, the Canadian Installation Codes (for General Installation and Gas Plumbing). It is
important that gas pressure regulators meet applicable pressure requirements and that gas meters be
rated for the total amount of all the appliance Btu’s being supplied.

The dryer is provided with a 1 inch N.P.T. inlet pipe connection extending out the back area

of the burner box. The minimum pipe size connection (supply line) to the dryer is 1 inch N.P.T. For
ease of servicing, the gas supply line of each dryer must have its own shut-off valve.

The size of the main gas supply line (header) will vary depending on the distance this line

travels from the gas meter or, in the case of L.P. gas, the supply tank, other gas – operated
appliances on the same supply line, etc. Specific information regarding supply line size should be
determined by the gas supplier.

NOTE:

Undersized gas supply piping can create a low or inconsistent pressure which will
result in erratic operation of the burner ignition system.

Consistent gas pressure is essential at ALL gas connections. It is recommended that a 1-inch

pipe gas loop be installed in the supply line serving a bank of dryers. An in-line pressure regulator
must be installed in the gas supply line (header) if the (natural) gas pressure exceeds 12.0 inches of
water column pressure.

IMPORTANT: A water column pressure of 3.5 to 4.0 inches for natural gas and 11.0 inches for

L.P. dryers is required at the gas valve pressure tap of each dryer for proper and
safe operation.

A 1/8 inch N.P.T. plugged tap, accessible for a test gauge connection, must be installed in

the main gas supply line immediately upstream of each dryer.

IMPORTANT: Pipe joint compounds that resist the action of natural and L.P gases must be used.

IMPORTANT: Test all connections for leaks by brushing on a soapy water solution (liquid

detergent works well).

WARNING:

NEVER TEST FOR GAS LEAKS WITH A FLAME!!!

All components / materials must conform to National Fuel Gas Code Specifications ANSI

2223.1 – LATEST EDITION, or in CANADA, the Canadian Installation Codes CAN/CGA –
B149.1 – M91 (Natural Gas) or CAN/CGA – B149.2 – M91 (L.P. Gas) or LATEST EDITION.

It is important that gas pressure regulators meet applicable pressure requirements, and that

gas meters be rated for the total amount of appliance Btu’s being supplied.

IMPORTANT: The dryer and its individual shut – off valve must be disconnected from the gas

supply piping system during any pressure testing of that system at test pressures
in excess of 1/2 psig (3.5 kPa).

NOTE:

The dryer must be isolated from the gas supply piping system by closing its
individual manual shut off valve during any pressure testing of the gas supply
piping system at test pressures equal to or less than 1/2 psig (3.5 kPa).
