6-28 Adit 3000 (Rel. 1.6) and MSR Card (Rel 2.0) GUI
Voice over IP
Trunk Settings
Identification
Trunk ID Display/edit the Trunk ID. A default ID is assigned. The Trunk ID can
have up to 20 characters.
Description Display/edit a Trunk Description. By default they are named Trunk n.
Packet Processing
Codec Pref1
Codec Pref2
Codec Pref3 Define the preference order of the Codecs.
G.711u - G.711 mu-law
G.711A - G.711 A-law
G.729A - G.729 A-law
None
Fax Mode None - A Fax call will be treated as a normal voice call. Default.
Bypass - Will cause the line to transmit in G.711 mode, with silence
suppression disabled, on detection of Fax tone.
T38 - The Adit MSR will support T.38 in a future release.
Modem/SuperG3 Fax
Mode None - A Modem call will be treated as a normal voice call. Default.
Bypass - Will cause the line to transmit in G.711 mode, with silence
suppression disabled, on detection of Modem tone.
Silence Suppression Enable or disable silence suppression for voice calls, for one or
more voice channels.
Jitter Buffer Static - Maintain a static average delay, = 2x the packet time (Default)
Dynamic - Perform dynamic delay adjustment to minimize delay
Voice Processing
Transmit Gain Set the gain on the transmit side voice path for the specified voice
channel(s).
Range is -12 to 6, with a default of 0.
Receive Gain Set gain on the receive side voice path for the specified voice
channel(s).
Range is -12 to 6, with a default of 0.
Echo Cancellation Check to enable Echo Cancellation on this trunk.
Calling Features
Block Outgoing Caller
ID Enables/disables blocking of Caller ID on SIP calls made from this
trunk.
Authentication
Authentication Check to enable authentication on this trunk.
Authentication User ID Enter User ID.
Authentication
Password
Enter Authentication Password.
Field Definition (Continued)
