C
HAPTER
3
Network Connections
In this Chapter
Overview
-
Adit 3000 Connections
- Adit MSR Connections
Preconfigured Connections
-
Ethernet 1
- Ethernet 2
- Serial 1 (Adit 3000 Only)
- T1 1 - T1 4 (Adit 3000 Only)
Connections that Require Configuration
-
Multilink
- Serial (PPPoDS0)
New Connection
-
Point-to-Point Protocol over DS0 (Serial)
- Multilink Point-to-Point Protocol over DS0 (Multilink)
- Point-to-Point Tunneling Protocol (PPTP)
- Point-to-Point Tunneling Protocol Server (PPTP Server)
- Layer Two Tunneling Protocol (L2TP)
- Internet Protocol Security (IPSec)
OSPF Configuration on the Network Connection
