6-24 Adit 3000 (Rel. 1.6) and MSR Card (Rel 2.0) GUI
Voice over IP
Line Monitoring
The following table defines the fields displayed in the Line Monitoring window:
Field Definition
Registration Address Adit WAN IP address. Blank if a proxy has not been selected.
SIP Proxy Indicates if SIP proxy is selected or not.
Line Specific FXS line.
User ID Displays the User ID.
Phone Status Displays the Phone status - Idle, dialing in progress, ringing, call in
progress, etc.
Registration Status Displays registration status - Registered or failed.
RTP RX/TX/Lost
(Packets) Packets received/transmitted/dropped.
Jitter (ms) Milliseconds of Jitter incurred on the call.
Overflow There are too many packets to buffer.
