3-34 Adit 3000 (Rel. 1.6) and MSR Card (Rel 2.0) GUI
Network Connections
New Connection
Point-to-Point Tunneling Protocol (PPTP)
Point-to-Point Tunneling Protocol enables secure transfer of data to another location over the Internet.
1. Select Network Connections/New Connection.
2. Select Point-to-Point Tunneling Protocol (PPTP), then select Next >.
3. Configure the Client Connection Properties:
4. Select Next >.
5. Select 3 Finish.
Field Definition
Host Name or IP Address of
Destination Enter the Remote Server Host Name or IP Address.
Login User Name Enter the User Name for the above server.
Login Password Enter the Password for the above User Name.
