Adit 3000 (Rel. 1.6) and MSR Card (Rel 2.0) GUI 6-5
Voice over IP
IP Telephony
Proxy Servers
Proxy Type This drop-down menu allows users to select the proxy type:
Generic
BroadSoft (Info)
Sylantro
Lucent (Info)
Route Direct Phone
Entries in Phone
book through Proxy Select the checkbox to enable.
Enabled/Disable Enable or disable the features listed below.
Use SIP Proxy Select to enable, and enter the IP/DNS address of the SIP Proxy.
Port Enter SIP Proxy port where SIP requests are to be sent. Range is
1024-65535, with a default of 5060.
Use SIP Outbound
Proxy Select to enable, and enter the IP address of the SIP Outbound Proxy. An
outbound proxy is one to which all outgoing SIP requests are sent.
Port Enter SIP Outbound Proxy port. Range is 1024-65535, default of 5060.
Codecs
Supported Codecs Allows the user to select which codecs are to be enabled and provides a
drop-down menu to select the packetization time (ms):
G.711, 64kbps, u-Law = 10, 20, 30, 40, 50 or 60 (default is 20)
G.711, 64kbps, A-Law = 10, 20, 30, 40, 50 or 60 (default is 20)
G.729, 8kbps = 10, 20, 30, 40, 50, 60, 70 or 80 (default is 20)
Field Definition (Continued)
