Adit 3000 (Rel. 1.6) and MSR Card (Rel 2.0) GUI 3-39
Network Connections
New Connection
4. Select the Remote Address and Subnet types, and select Next >.
Note: The following example assumes a selection of Network-to-Network/Remote Gateway
Address and Remote Subnet. This example displays the most options.
5. Configure the IPSec connection properties:
6. Select Next >.
7. Select 3 Finish.
Field Definition
Remote Tunnel Endpoint Address Enter the Remote Server IP Address.
Remote Subnet Remote Subnet IP Address - Enter the remote subnet
IP Address
Remote Subnet Mask - Enter the subnet mask for the
above subnet address.
Shared Secret Enter a shared secret key, with a maximum of 30
characters.
