1-12 Adit 3000 (Rel. 1.6) and MSR Card (Rel 2.0) GUI
Web Based Management
Quick Setup
Manual IP Address Ethernet Connection
This window is used to manually configure the Internet Connection with a specific IP Address.
Field Definition
IP Address Enter the IP Address for the Ethernet connection of this device.
Subnet Mask Enter the Subnet Mask for the IP Address above.
Default Gateway Enter the Default Gateway address for this device.
Primary DNS Server Enter the Primary DNS Service address.
Secondary DNS Server Enter the Secondary DNS Service address.
