Voice over IP
Trunk Settings
Field
Definition
General
Connection
Adit 3500:
Connections are T1 #1 through T1 #4. Select the checkbox for the T1
to apply the trunk settings to. Note: A red
X
indicates that the T1 is not
available.
Adit MSR:
Connections are LCC #1 through LCC #8. Select the checkbox for the
LCC to apply the trunk settings to. Note: A red
X
indicates that the
LCC is not available.
Note: For the Adit MSR, when you select an LCC and apply it to the
trunk, the cross-connect status is displayed below the link number.
The status indications are:
No cross-connect - No cross-connect has been made for the selected
link.
Cross-connected to x - A cross-connect with compatible protocol
has been made. (x is the name of the cross-connected entity on the
controller. For example, a:1:1-24.)
Incompatible CAS/PRI Protocol on x - There is an incompatibility
in signaling protocol or link selection between the controller and
MSR card. (x is defined as above.)
Note: When you select the connection’s name, the Channel
Configuration appears. See the Channel Configuration on page 6-30.
Interface Type
Displays the interface type (Network).
Trunk Signaling
Sets the signaling type of the trunk.
PRI - Primary Rate Interface
CAS - Channel Associated Signaling
Signaling Type
Sets the signaling type protocol on the trunk. Note: Hunt sequence of
the PRI is a Round-Robin type, and is not configurable.
If PRI is selected above:
PRI-ni2 - The CCITT National ISDN 2 PRI standard.
PRI-4ess - The class 4 US AT&T proprietary version of ISDN.
PRI-5ess - The class 5 ISDN central office circuit switching
system developed by AT&T.
PRI-dms100 - Digital central office switch (number 100) from
Northern Telecom.
If CAS is selected above:
EM Wink Start - E&M Wink Start.
EM Immediate Start - E&M Immediate Start.
EM Delay Wink Start - E&M Delay Wink Start.
PCM Coding
Displays the defined Pulse Code Modulation.
Terminal Endpoint
Identifier
Displays the Terminal Endpoint Identifier for the trunk.
