96
920i Installation Manual
Command
Description
Values
SC.SRC#n
Scale source
Specify scale source as: SC.SRC#n = y, z.a
y Scale type:
A
A/D scale
B
Analog input
S
Serial scale or
iQUBE
2
T
Total scale
P
Program scale
z
Port number (for serial scale or
iQUBE
2
only)
.a
iQUBE
2
system identifier (defaults to .1)
SC.GRADS#n
Graduations
1–9999999
SC.SPLIT#n
Multi-range or multi-interval
scale type
OFF, 2RNG, 3RNG, 2INTVL, 3INTVL
SC.ZTRKBND#n
Zero track band
0, 0–100
SC.ZRANGE#n
Zero range
1.900000, 0–100
SC.MOTBAND#n
Motion band
1, 0–100
SC.SSTIME#n
Standstill time
1–65535
SC.OVRLOAD#n
Overload
FS+2%, FS+1D, FS+9D, FS
SC.WMTTHRH#n
Weighment threshold
grads
SC.NUMWEIGH#n
Number of weighments
—
SC.MAX_WEIGHT#n
Maximum weight
—
SC.DIGFLTR1#n
SC.DIGFLTR2#n
SC.DIGFLTR3#n
Digital filtering
1, 2, 4, 8, 16, 32, 64, 128, 256
SC.DFSENS#n
Digital filter cutout sensitivity
2OUT, 4OUT, 8OUT, 16OUT, 32OUT, 64OUT, 128OUT
SC.DFTHRH#n
Digital filter cutout threshold
NONE, 2D, 5D, 10D, 20D, 50D, 100D, 200D, 250D
SC.RATLTRAP#n
Rattletrap filtering
OFF, ON
SC.SMPRAT#n
Sample rate
30HZ, 60HZ, 120HZ, 240HZ, 480HZ, 960HZ
SC.PWRUPMD#n
Power up mode
GO, DELAY
SC.TAREFN#n
Tare function
BOTH, NOTARE, PBTARE, KEYED
SC.PRI.DECPNT#n
Primary units decimal position
8.888888, 88.88888, 888.8888, 8888.888, 88888.88, 888888.8,
8888888, 8888880, 8888800
SC.PRI.DSPDIV#n
Primary units display divisions
1D, 2D, 5D
SC.PRI.UNITS#n
Primary units
LB, KG, G, OZ, TN, T, GN, TROYOZ, TROYLB, LT, CUSTOM, NONE,
OFF
SC.PRI.CUNITS#n
Primary custom units
Specify units if SC.PRI.UNITS=CUSTOM
SC.SEC.DECPNT#n
Secondary units decimal
position
8.888888, 88.88888, 888.8888, 8888.888, 88888.88, 888888.8,
8888888, 8888880, 8888800
SC.SEC.DSPDIV#n
Secondary units display
divisions
1D, 2D, 5D
SC.SEC.UNITS#n
Secondary units
LB, KG, G, OZ, TN, T, GN, TROYOZ, TROYLB, LT, CUSTOM, NONE,
OFF
SC.SEC.CUNITS#n
Secondary custom units
Specify units if SC.SEC.UNITS=CUSTOM
SC.SEC.MULT#n
Secondary units multiplier
0.00000–9999999
SC.TER.UNITS#n
Tertiary units
LB, KG, G, OZ, TN, T, GN, TROYOZ, TROYLB, LT, CUSTOM, NONE.
OFF
SC.TER.CUNITS#n
Tertiary custom units
Specify units if SC.TER.UNITS=CUSTOM
Table 10-4. SCALES Serial Commands
