2000-600-02 Manual Loader
Ball Handle Adaptor
Wrenches featuring a ball handle are fixtured using the ball
handle reaction adaptor shown in Figure 6-4. Install the adaptor
onto the reaction slide using both reaction pins. Fix the adaptor
height with the threaded knob.
Figure 6-4: Ball Handle Adaptor
