4-16

Using the MULTITEST Toque Calbration System

Torque-Angle Algorithm

In addition to MULTITEST series torque transducers, the

MULTITEST Indicator accepts input from common bi-directional

incremental rotary encoders. The Indicator features a special

Torque-Angle measurement mode where a clamping torque is

first applied and measured, then at torque preset coincidence,

(when the input torque matches the SET LOW limit), the

Indicator automatically switches to measuring angle in degrees

of rotation.

The operator continues to rotate the fastener until angle preset

coincidence (angle matches the SET HIGH limit). With this, the

specified torque and angle parameters are accomplished in one

wrenching operation.

For additional information on setting up angle encoders,

programming a particular angle and measurement modes, refer

to Chapter 3—Set Up and Programming in this manual.

1. Press MODE to select ANGLE.

— The LED display reads:

0

— The LCD angle display is blank at the lower left, as

shown in Figure 4-6.

2. Install the angle encoder and torque transducer between

the fastener and an appropriate wrench or breaker bar.

3. With the encoder reference arm, strap, clamp or magnet

fixed to the work, rotate fastener while monitoring torque

on the LED display. At torque preset coincidence, (when

the torque measurement matches the SET LOW torque

limit) the Indicator sounds a momentary tone and initiates

display of degrees of rotation on the LCD.

4. Continue rotating the fastener until angle preset

coincidence (when the angle measurement matches the

SET HIGH angle limit). The Indicator sounds a pulsating

tone. The LED display holds the peak torque applied

and reads:

A+torque (angle plus torque)

5. Press MANUAL CLEAR to zero the torque and angle

displays.
