CDI Torque MULTITEST Government - Manual (Page 3)

Suggested Transducer Calibration Check Points, Bars, Hangers and Weights
for 2500-400-02 (Multiple Transducer Assembly, 0.25% Accuracy)
Bar Hanger Calibration Check Weights to Add Total
Range Length Weight Points Points (n) = more than 1 Weight
40 - 400 in oz 5" 1/2 lb 1 40.0 in oz 40 in oz none 1/2 lb
5" 1/2 lb 2 80.0 in oz 80 in oz 1/2 lb 1 lb
5" 1/2 lb 3 160.0 in oz 160 in oz 1/2 lb, 1 lb 2 lb
5" 1/2 lb 4 240.0 in oz 240 in oz 1/2 lb, (2) 1 lb 3 lb
5" 1/2 lb 5 400.0 in oz 400 in oz 1/2 lb, (2) 2 lb 5 lb
5" 1/2 lb 3.75 in lb 4 oz 0.75 lb 3.75 - 50 in lb
5" 1/2 lb 1 5.0 in lb 5.0 in lb 1/2 lb 1 lb
5" 1/2 lb 2 10.0 in lb 10 in lb 1/2 lb, 1 lb 2 lb
5" 1/2 lb 3 20.0 in lb 20 in lb 1/2 lb, 1 lb, 2 lb 4 lb
5" 1/2 lb 4 30.0 in lb 30 in lb 1/2 lb, 1 lb, (2) 2 lb 6 lb
5" 1/2 lb 10 in lb 1/2 lb, 1 lb 2 lb 10 - 150 in lb
5" 1/2 lb 1 15.0 in lb 15 in lb 1/2 lb, 2 lb 3 lb
5" 1/2 lb 2 30.0 in lb 30 in lb 1/2 lb, 1 lb, (2) 2 lb 6 lb
5" 1/2 lb 3 60.0 in lb 60 in lb 1/2 lb, 1 lb, (2) 5 lb 12 lb
5" 1/2 lb 4 90.0 in lb 90 in lb 1/2 lb, 2 lb, (3) 5 lb 18 lb
5" 1/2 lb 5 150.0 in lb 150 in lb 1/2 lb, (2) 2 lb, (5) 5 lb 30 lb
30 - 400 in lb 10" 1/2 lb 30 in lb 1/2 lb, 2 lb 3 lb
10" 1/2 lb 1 40.0 in lb 40 in lb 1/2 lb, 1 lb, 2 lb 4 lb
10" 1/2 lb 2 80.0 in lb 80 in lb 1/2 lb, 2 lb, 5 lb 8 lb
10" 1/2 lb 3 160.0 in lb 160 in lb 1/2 lb, (3) 5 lb 16 lb
10" 1/2 lb 4 240.0 in lb 240 in lb 1/2 lb,1 lb, 2 lb, (4) 5 lb 24 lb
10" 1/2 lb 5 400.0 in lb 400 in lb 1/2 lb,1 lb (4) 2 lb, (6) 5 lb 40 lb
5" 1/2 lb 5 50.0 in lb 50 in lb 1/2 lb, 1 lb, (4) 2 lb 10 lb
Amendment for Multitest Loader Manual: May 24, 2006
