G — Front Panel Membrane Function Keys
Toggles between TORQUE and FORCE measurement modes.
Selects TRACK, PEAK HOLD, POWER TOOL, FIRST PEAK
and ANGLE modes.
display:
Selects following units on LCD
Torque units in: Nm, dNm, cNm, mkg, cmkg, lb ft, in lb, in oz,
or
Force units in: N, dN, kp, gf, lbf, oz
Manually resets ANGLE display on LCD at any time.
Manually resets ZERO TARE.
Selects LED or LCD digit to right (blinking) for setup and
programming. Shift for printer and angle encoder programming.
Selects LED or LCD digit to left (blinking) for setup and
programming. Shift for printer and angle encoder programming.
Terminates calibration and program modes. Returns to 4-in-1
transducer scan.
Increments selected digit during calibration and program modes.
Scrolls statistical analysis display.
Decrements selected digit during calibration and program
modes. Scrolls statistical analysis display.
SELECT
UNIT
ANGLE
RESET
ZERO
TARE
MODE
DIGIT
DIGIT
ENTER
VALUE
VALUE
