Dell OptiPlex 360 (Late 2008) - Manual (Page 64)

64 Drives
Replacing or Adding a Floppy Drive or Media Card Reader in the Mini
Tower Computer
NOTE: This procedure assumes that you have completed the removal procedure
first.
1 If you are replacing a floppy drive or media card reader, remove the
shoulder screws from the existing drive and attach the screws to the
replacement drive.
2 If you are installing a new floppy drive or media card reader:
a Remove the drive panel insert installed in the drive bay.
b Remove the four shoulder screws from the drive panel insert.
c Attach the shoulder screws to the new drive or media card reader.
3 Align the shoulder screws on the floppy drive or media card reader with the
shoulder screw guides in the bay, and gently slide the drive into the bay
until it clicks into place.
1 drive release latch 2 floppy drive
Drive Panel Insert
