*NOTE: Pan mode may be turned on for the 1280 x 1024 (super XGA [SXGA]), 1400 x 1050 (SXGA Plus), and 1600 x 1200 (ultra graphics
array [UGA]) computer displays. In pan mode the screen resolution is too high to be completely displayed on the computer display. For
example, the taskbar that usually appears at the bottom of the desktop may no longer be visible. To view the rest of the screen, use the touch
pad or track stick to pan up and down and left and right.
To display more colors, select a lower resolution. If you select a resolution and color combination that the system does not support, the system
automatically selects the next supported combination.
Table 3 lists the maximum color depth possible for various combinations of resolutions without DVD and 3D.
Table 3. Display Resolution and Color Depth Without DVD and 3D Running
640 x 480 (VGA)
4.2 B (32-bit)
60, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
800 x 600 (super VGA [SVGA])
256 (8-bit)
60, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
800 x 600 (SVGA)
65 k (16-bit)
60, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
800 x 600 (SVGA)
16 M (24-bit)
60, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
800 x 600 (SVGA)
4.2 B (32-bit)
60, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1024 x 768 (XGA)
256 (8-bit)
60, 70, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1024 x 768 (XGA)
65 k (16-bit)
60, 70, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1024 x 768 (XGA)
16 M (24-bit)
60, 70, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1024 x 768 (XGA)
4.2 B (32-bit)
60, 70, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1280 x 1024 (SXGA)*
256 (8-bit)
60, 70, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1280 x 1024 (SXGA)*
65 k (16-bit)
60, 70, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1280 x 1024 (SXGA)*
16 M (24-bit)
60, 70, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1280 x 1024 (SXGA)*
4.2 B (32-bit)
60, 70, 75, 85 Hz
60 Hz NTSC, 50 Hz PAL
1400 x 1050 (SXGA Plus)*
256 (8-bit)
60 Hz
60 Hz NTSC, 50 Hz PAL
1400 x 1050 (SXGA Plus)*
65 k (16-bit)
60 Hz
60 Hz NTSC, 50 Hz PAL
1400 x 1050 (SXGA Plus)*
16 M (24-bit)
60 Hz
60 Hz NTSC, 50 Hz PAL
1400 x 1050 (SXGA Plus)*
4.2 B (32-bit)
60 Hz
60 Hz NTSC, 50 Hz PAL
1600 x 1200 (UGA)*
256 (8-bit)
60 Hz
60 Hz NTSC, 50 Hz PAL
1600 x 1200 (UGA)*
65 k (16-bit)
60 Hz
60 Hz NTSC, 50 Hz PAL
1600 x 1200 (UGA)*
16 M (24-bit)
60 Hz
60 Hz NTSC, 50 Hz PAL
1600 x 1200 (UGA)*
4.2 B (32-bit)
60 Hz
60 Hz NTSC, 50 Hz PAL
NOTE: Color depth is based on 256 colors for 8 bit, 65,536 colors for 16 bit, 16,842,752 colors for 24 bit, and 4,294,967,296 colors for
32 bit displays.
Maximum Color Depth Possible (in bits)
Secondary
640 x 480 800 x 600 1024 x 768 1280 x 1024
Primary
640 x 480 (8 bit)
32
32
32
32
800 x 600 (8 bit)
32
32
32
32
1024 x 768 (8 bit)
32
32
32
32
1280 x 1024 (8 bit)
32
32
32
32
1600 x 1200 (8 bit)
32
32
32
32
640 x 480 (16 bit)
32
32
32
32
