60
1-7. Download Raw Plate Data Format
All protocol data is ASCII code data.
Transmit format: <“,”(0x2c)><“,”><“,”>…<“,”>
“,”(0x2c) delimits each parameters item.
1-7-1. End point's Download Raw Plate Data Format
The assignment of the Download Raw Plate Data format of End point:
# Item of the plate datum Details
1 Plate data mode “0”(End point), “1”(Kinetic)
2 Memory number "1" to "10" (End point), "1" or "2" (Kinetic)
3 Kit name [16] ASCII characters (max 15characters + null code)
4 Plate reading mode (S/D) Plate reading mode (“0”: Single / “1”: Dual)
5 Measurement wavelength Model 680: “400” to “750”nm
6 Reference wavelength
Model 680: “400” to “750”nm
A space character (0x20) is available for Single reading.
7 Measurement filter number “1” to “8”
8 Reference filter number
“1” to “8”
A space character (0x20) is available for Single reading.
9 Protocol number "1" to "64" (End point), "65" or "66" (Kinetic)
10 Plate reading date
”/”“/””:”“:”
: "00" to "99" (2000 to 2099)
: "1" to "12"
: "1" to "31"
: "0" to "23"
: "0" to "59"
: "0" to "59"
11 Begin of "begin"
12
: Abs. Data
(See below "Abs. Data Sample")
Measurement wavelength absorbance values are in ASCII encoded
floating point format. Ex. 0.000
Each absorbance value is separated by a space, but in case of minus
value, a minus sign is put instead. Each row of 12 well values is
separated by a comma (,).
<8 rows of 12 wells of abs. values>:
Row1=wells (A1 to A12)"," Row2=wells (B1 to B12)","…
…. Row8=wells (H1 to H12)
13 End of "end"
14 Begin of "begin", put only for dual wavelength reading
15
: Abs. data, put only for dual wavelength reading
(See below "Abs. Data Sample")
<8 rows of 12 wells of abs. values>:
Row1=wells (A1 to A12)"," Row2=wells (B1 to B12)","…
…. Row8=wells (H1 to H12)
16 End of "end", put only for dual wavelength reading
