Plate mapping, Kit name setting, Selecting reading speed – Bio-Rad Model 680 Microplate Reader Accessories User Manual
Page 28: Incubator parameter setting, Selecting kinetic assay type, Selecting report type, Calculation parameter setting

24
Kit name for #01
»G.A.P. TEST IgG«
↑
[ABC]
Kit name
Calculation
Mapping
Assay
Assay type selection
»■[General KINETIC]
GALT assay
Calculation Param.
CC Limit:
0.910
Calc.range:
10
-
20
Select Mapping mode
»■Manual mapping
•Automatic mapping
»■[Lin.regression]
•Absorbance
•KINETIC Plots
Report
Plate Mapping
See Plate Map setting procedure.
Result = (R2 – R1)*k
k =
9999.99
R1:1st Reading
R2:2nd Reading
If GALT
Set Incubation param
Incubator:
Enable
Temperature:
37.5
Reading speed
[Fast mode]
Step mode
Speed
Incubation setting
Kit name setting
Use the Up and Down arrow keys to select alphabet from “A” to “Z” and space.
Use the Number keys for numeric input.
Right arrow key to move the cursor to the right.
Left arrow key to slip out of the screen and it returns to the Protocol Menu
screen.
Pressing “./FUNC” key will change the character mode: Upper case alphabet ->
Lower case alphabet -> symbol. Current character mode is indicated on the
lower right corner of the LCD.
Selecting Reading Speed
Pressing the Up or Down arrow keys will switch the selection. Press
Enter to complete the selection.
Incubator parameter setting
When the “Incubator” field is activated, pressing the Right arrow key will
switch the field entry: “Enable” <-> ”Disable”.
Pressing the Up or Down arrow keys will move the cursor to the next
entry field. When the Temperature field is activated enter the temperature
value using the numeral keys. Press Enter to complete all field entries.
This setting is available only when the Incubator is installed in the system.
Kinetic Protocol Menu
Selecting Kinetic Assay type
Move the cursor to the desired Assay type by pressing the Up or Down arrow
keys. Press Enter to complete the selection.
The item with mark “[ ]” is the currently selected item.
GALT assay: Result = factor x (2nd Read – 1st Read)
Selecting report type
Move the cursor to the desired report type by pressing the Up or Down arrow
keys. Pressing the Right arrow key will select or deselect the item.
Press Enter to complete the selection.
Note: When GALT assay is selected “GALT report” shall be the only one option
on this screen.
»■Mode •Report
•Calc. •Kit name
•Mapping
•Assay
Calculation Parameter setting
When the “CC Limit” field is activated, pressing the numeral key will enter the
desired numbers. Press Enter to complete all field entries.
If the GALT Reports is activated, pressing the numeral keys will enter the
desired numbers. Press Enter to complete all field entries.
