3 | Image Lab Software Overview
58 | Gel Doc EZ Imaging System with Image Lab Software
Main Toolbar
Many Image Lab tools can be selected by clicking toolbar buttons. The Screenshot
tool enables you to send a screen capture of your image to the clipboard or to save
it as a file. You can view demonstrations of various functions by clicking Tutorials.
The unlimited Undo and Redo buttons enable you to correct missteps easily. The
Default Protocols tool at the right end of the toolbar enables you to set up, view, and
edit default protocols.
File management View results data
Results Data
Results data associated with gel images can be viewed as an analysis table, a lane
profile, a standard curve, or in a report. Different tools for viewing the results data
are easily accessible from the main toolbar. These tools are described in Chapter 5,
Viewing Images . The views display the analysis for the selected image. All of the
views can be displayed at the same time. See Displaying Data on page 96 for
details.
Display Toolbox
The display toolbox at the top of every image enables you to display images in the
most useful ways. See Chapter 5, Viewing Images for a description of each option.
