3-42 ADS FlowAlert Manual
Connecting the Sensor and Float to
the Monitor
After installing the pressure depth sensor and the float switch and
completely securing their cables, connect the sensor and/or float to
the FLOATS/PRESSURE port on the top of the monitor.
Applications involving pressure depth sensors and customer
supplied floats/relays require connecting an intermediate adapter
cable (pigtail) between the sensor/customer-supplied hardware and
the monitor.
The following table indicates the part numbers for the cables and
pigtails required for each application:
Description ADS Part Number
Floats & Pressure pigtail (for
customer-supplied floats or relay
contacts)
6000-0013
Pressure pigtail 6000-0014
Floats pigtail (for customer-supplied
floats or relay contacts)
6000-0021
1 float 6000-0015-20/40/60
2 floats 6000-0025-20/40/60
2 floats & pressure pigtail 6000-0026-20/40/60
1 float & pressure pigtail 6000-0027-20/40/60
Connect the cables to the monitor port in the following way:
1. Place the monitor in an upright position to view the monitor
connector ports.
