A p p e n d i x a specifications, Ads flowalert monitor (ads p/n 6000-fal/faw), Specifications – ADS Environmental Services FlowAlert QR 775011 A2 User Manual
Page 188: Ads flowalert monitor (ads p/n 6000- fal/faw)
A-1
A P P E N D I X A
Specifications
This appendix contains specifications for the ADS
FlowAlert
monitor, printed circuit board/digital signal processor, pressure
depth sensor, float switch, and lightning protection module.
ADS FlowAlert Monitor (ADS p/n 6000-
FAL/FAW)
The following table contains the specifications for the FlowAlert
monitor.
Note: Currently, FlowAlert monitors are not intrinsically
safe.
Enclosure
Cylindrical 0.13-inch (0.30 cm) thick seamless,
marine-grade aluminum with stainless steel hardware
Dimensions
11.5 inches long by 6.38 inches diameter
Weight
22 pounds (monitor with battery)
Operating
Temperature
32
° to 140° F (0° to 60° C)
