Specifications A-3
Printed Circuit Board (ADS p/n 6000-0001)
The following table contains the specifications for the printed
circuit board.
Processor Texas Instruments VC33 DSP (Digital Signal
Processor)
Functions Performs and processes all requests for sensor
and diagnostic information, executes all math
calculations, performs MLI-related functions
based on user configuration, performs alarm
handling, and performs multi-tasking monitor
operations
Memory 1 megabyte non-volatile (program, configuration,
and data storage); 512 kilobytes static RAM
Data Storage 365 days (1 pressure and 2 float readings at a 15-
minute sample rate)
Sample Rates Minutes: 1, 2, 5, 15, 30
Hours: 1, 2, 12, 24
Clock Battery backed RTC module
Communications Landline: Multitech Model MT5600SMI; FCC ID
6KDMD06AHS1; 19.2K baud with fallback to
9600 and 1200 as required for reliable
communication; regular 2-wire voice grade POTS
service line
Wireless: Enfora ™ Dual band 850/1900 MHZ
GSM/GPRS; FCC ID MIVGSM0108; fixed
address via AT&T custom APN; refreshed every 4
hours via hard-attach
Serial/Direct Connect: RS-232
Comm Protocol AccuYapp for configuration and diagnostics
Yapp for data collection and cryouts
Antenna ADS whip or direct burial
