7. Setup
93
7-4.1. Camera ON/OFF
▫ Click on each of the channels to select the “
O ” or “
X ” in the CAMERA menu. If the “
O ” is
selected, the corresponding video channels (CAM 01 through CAM 08) will be displayed
on the screen. If the “
X ” is selected, the corresponding video channels (CAM 01 through
CAM 08) won’t be displayed.
[Fig. 7-30 Camera ON/OFF button]
7-4.2. Camera Name (Camera Title)
▫ Click the NAME (Camera Title) button in the CAMERA menu and then the On Screen
Keyboard will be displayed as shown in [Fig. 7-31].
▫ Delete the existing NAME (Camera Title) with the button on the On Screen Keyboard.
▫ Enter the new NAME up to 8 Characters by using the On Screen Keyboard and click on the
OK button to save. Click on the CANCEL button to cancel.
▫ Click the (EXIT) button to return to the SETUP menu.
[Fig. 7-31 Camera Name Setting Keyboard window]
