6. How to Operate
55
6-8.2. VGA OUTPUT CONFIG (SCALE / CONTRAST / BRIGHTNESS / SATURATION)
▫ To Setup the SCALE / CONTRAST / BRIGHTNESS / SATURATION of VGA Output, click
the VGA OUTPUT in the VIDEO ENHANCE menu and then the VGA ENHANCE menu will
display as shown in [Fig. 6-28].
▫ Select one of Scales (Aspect Ratio) between 16:10 and 4:3 by clicking the box. The default
value is 16:10.
▫ Adjust the Contrast, Brightness and Saturation by using the sliders or clicking the slider
bars.
▫ To Return to the VIDEO Enhance menu, click the (EXIT) button on the VGA
ENHANCE menu.
[Fig. 6-28 VGA ENHANCE menu]
