Stand-alone DVR Instruction Manual
18
LCD
Display 20.1” TFT LCD active matrix
Pixel Pitch 0.258 mm x 0.258mm
Active Display Area 433.44(H) x 270.90(V) mm
Display Colors 16.7M (Hi-FRC)
Display Mode Normally White
Pixel Arrangement RGB vertical stripe
Luminance of White 300 cd/㎡
Contrast Ratio 1,000 : 1
Viewing Angle L/R/U/D 85 / 85 / 75 / 85 degree
Operating Temperature 0℃ ~ 60℃
Storage Temperature -25℃ ~ 60℃
[Fig. 4-1 Specifications]
Design and the specifications are subject to change without notice.
