Stand-alone DVR Instruction Manual
138
Table. Description of Remote Host Program Button
① Minimization Button
② Close Button
③ Current Time
④ Connection Button
⑤ Setup Button
⑥ Player Execution Button
⑦ Capture Button
⑧ Multi-Mode
⑨ Terminal Mode
⑩ E-map Button
⑪ Splits the screen in 4, 8Ch.
○ 12 PAN /TILT Control Button ( Control the PTZ camera from the remote site DVR)
○ 13 Depending on the mode, it displays Status/REPLAY / COPY information.
○ 14 Change button for STATUS / REPLAY/ COPY mode.
○ 15 When connected, it displays the audio channel, PC Speaker & Mic control button of remote site DVR.
○ 16 It displays the IP address, Frame rate and transfer rate.
