8. REMOTE HOST PROGRAM
145
8-4.5. Replay
It is possible to replay the recorded data from the DVR system by using the Replay button in
[Fig. 8-10] in the Multi mode only (refer to section 8-4.9.2).
- Click the Replay button as shown in [Fig. 8-10] to playback the recorded data from the DVR
system, and then the Replay Time Setup Window will be displayed.
[Fig. 8-10 Replay mode]
- After checking the Start Time and End Time on the upper part of the Replay Time Setup
Window, click the Edit (
) button to set the Replay Start Time.
- Set the Replay Start Time in the Start Time Setting menu as shown in [Fig. 8-11] and click the
OK button. Replaying start time setup can be possible within a recoding time extent.
- Click the Play (
) button.
- It will start playing the recorded data and the playback control buttons will show up.
[Fig. 8-11 Start Time setting]
REPLAY button
Replay Time Setup Window
