Stand-alone DVR Instruction Manual
144
8-4.4. Status
If the Status button on the DvrMaster is selected by clicking the mouse, the DvrMaster displays
the DVR’s status related to connections of cameras, sensors, relay outputs and remaining
HDD (Hard Disk Drive) capacity available for recording.
[Fig. 8-9 STATUS MODE]
Status button
