7. Setup
89
7-2.7. FIRMWARE UPDATE
There are two ways to update the firmware through USB memory and the DvrMaster (GUI).
We recommend users to update the firmware only in the LIVE mode.
▫ By USB memory
- Format the USB with your computer and save the firmware file on it (not including
folder).
- Plug it on the USB port on the DVR.
- Click the mouse on the SELECT button in the SYSTEM menu and the FIRMWARE
LIST will be displayed.
- Click on the list, and then You will be asked, OK or CANCEL.
- Click the OK button to update the firmware and the system will automatically start
rebooting.
- Click the CANCEL button to cancel.
▫ By DvrMaster (GUI)
Refer to section 8-4.1 ○ 6 Firmware Update on page 140.
7-2.8. SYSTEM INFO
▫ Click the “SYSTEM INFO” button in the SYSTEM menu and then the SYSTEM INFO that
contains the system version and the last updated date will be displayed.
▫ Click the (EXIT) button to return to the SETUP menu.
[Fig. 7-24 SYSTEM INFORMATION window]
