Stand-alone DVR
Instruction Manual
104
7-6.4. All Sensors ON / OFF
▫ Click the
button in the RECORD menu, then the ALL SENSOR setup pop-up window
will be displayed as shown in [Fig. 7-62].
▫ By clicking the mouse, select the
on the pop-up window (See [Fig. 7-62])
to enable the system to start recording by Sensor (Passive Infrared sensor) for all the
channels.
▫ By clicking the mouse, select the
on the pop-up window (See [Fig. 7-62])
to disable the system to start recording by Sensor (Passive Infrared sensor) for all the
channels.
[Fig. 7-61 All Sensor Setup button]
[Fig. 7-62 All Sensor Setup pop-up window]
7-6.5. Size (Recording Resolution)
Select the size of the screen for recording. The larger the size selected, the better display
quality is but the larger the data becomes.
▫ Click the SIZE (Recording Resolution) button on each of the channels in the RECORD
menu, then the SIZE (Recording Resolution) pop-up window will be displayed as shown in
[Fig. 7-64].
▫ Select one of the Resolution among D1, HALF D1 and CIF on the pop-up window by
clicking the mouse.
[Fig. 7-63 Record Size button]
