8. REMOTE HOST PROGRAM
135
8-3. Internet Explorer
When you are trying to use this function, it is highly recommended that the password should
be turned ON in the SYSTEM menu not to enable unauthorized personnel to access your
DVR system (See section 7-2.5).
Up to 10 users can remotely access your DVR with the HOST NAME.
How to setup the Internet Explorer
• Registration to the
www.dyndns.org
(See section 7-7.7.2
on page 125
).
• In the IP address box of Microsoft Internet Explorer, type the HOSET NAME (See [Fig.
8-2]) you entered in the DDNS menu and the PORT NUMBER of the DVR, and then you
will be asked to install the AciveX control software (See [Fig. 8-3]). You should type the
protocol (http:
//), the host name (example: cloverdvr1.dyndns.org) or the static IP
address (See Fig.8-2-1) and the port number (:5800) in the IP Address box.
[Fig. 8-2 Host Name]
[Fig.8-2-1 IP & Port]
[Fig. 8-3 DVR Master- Windows Internet Explorer]
