8. REMOTE HOST PROGRAM
163
⑤ Configuration
[Fig. 8-41 Configuration window]
-
If the “Fit to window” is selected in [Fig. 8-41], it will automatically fit to the Player window in
[Fig. 8-33] (720x480) even though the recorded data is CIF (360x240) in the playback
mode.
-
If the “Open Data Folder” is clicked in [Fig. 8-41], the folders relating to the DvrMaster such
as the Auto Save, AVI Files, Backup Files, Emap Files, Printed Files and System Files will
be displayed.
⑥ Print button
- Click the Print button when a full screen is replaying on the Player and the current images
will print out along with comments if you write down some comments in the Print Comment
Dialog as shown in [Fig. 8-42].
-
Click the OK button in the Print Comment Dialog regardless of the comments to print.
⑦ Capture button
- Click the Capture button when a full screen is replaying on the Player and the current
images will be saved in the Printed Files (Open Windows Explorer – click My Computer -
